The tool pre-registration, measurement and inspection machine is an indispensable and necessary tool for any type of workshop and for any type of application, from automotive to aerospace, oil & gas, etc.

In an industry where automation becomes a constant request a presetter with that provided an autofocus capability becomes a necessity.

The AUTOFOCUS function allows tools to be measured automatically, without the operator intervening manually. This mode is recommended for those who need to carry out measurements on multi-edged tools which would be very long if carried out manually and, above all, which reduces the risk of human error to a minimum.

Once the tool has been clamped, the operator will simply have to choose what type of measurement he wants to carry out (single cutting edge or multi-cutting edge) and what to measure (X, Z or both axes) and start the measurement cycle. Without having to enter the number of cutting edges to measure or any theoretical value, the software will automatically start the cycle and end it once the 360° rotation has been carried out.



AUTOMATIC: AUTOFOCUS FUNCTION: NO MEASUREMENT ERROR

FLEXIBLE: A MACHINE THAT ADAPTS TO YOUR NEEDS

EFFICIENT: INCREASE THE PRODUCTION PROCESS



Elbo Controlli NIKKEN has developed a system that adapts the peripheral rotation speed of the tool based on the maximum diameter to be measured: the constant peripheral speed avoids the introduction of errors, whether you are measuring a 2 mm diameter tool or a 200 mm one.

The new machine software guarantees high performance: it is the heart of innovation in our world, especially that which looks to evolution.

The evolution of our software increases the connections between operators, tools and machines in the smart factor- All this translates into a real increase in terms of quality and performance.

E46BA can be equipped with the new Automatic Tool Recognition system.

GENERAL FEATURES

  • Measuring range: max diameter 400 mm (radius 200 mm); max height 600 mm
  • Base and column in natural granite: max linearity error 8 µm/m
  • Steel base with 3 fixed and 1 adjustable feet
  • Linear guideways (2 X axis, 1 Z axis) with double recirculating ball bearings slides
  • Pneumatic axis movement unlock
  • Manual gross movement
  • Manual fine adjustment
  • ECN AS371 certified optical scales (resolution 1µm)
  • Vertical TFT 15,6" Full HD Touch Screen Monitor
  • Overall dimensions: L = 1136 mm, H = 1935 mm, D = 568 mm
  • Net weight: ~ 230 kg
X Axis Measure (Diameter) Z Axis Measure (Length) Natural Granite Base & Column Interchangeable Spindle Cartridge C Axis Display Spindle Body and Spindle Cartridge Interchangeable Spindle Max. Run-Out Error Automatic Rotation of the Spindle Spindle Index in four Angular Positions (0º, -90º, -180º, -270º) Spindle Rotation Brake Spindle Identification System (NFC recognition) Clamping System Tool Inspection Function/Capability Elbo Controlli NIKKEN Triple Camera System (Cutting Edge Inspection) Main Camera System Resolution Main Camera System Measuring Range (C-MOS Sensor Framed Image Area) Secondary 'Twin' Camera System Measuring Ranges (Framed Image Area) Main Camera Magnification Secondary 'Twin' Camera System Magnifications Elbo Controlli NIKKEN Certified Optical Scale Axes Resolution Elbo Controlli NIKKEN GS371 Certified 'Natural Granite' Optical Scale Axes Resolution Touch Screen System (Operator Interface) Keyboard and Mouse Electronics/Processor Firmware/Operating System Data Storage Elbo Controlli NIKKEN Tool Management Software Tool Set Management and Post Processor Universal Generation DXF File Import and Creation Balluff Read/Write Ready (Balluff Hardware Required)? Elbo Controlli NIKKEN TiD Ready? Elbo Controlli NIKKEN TP32 Ready? Elbo Controlli NIKKEN IS 'Integrated Solution' with Twin Screen and Dual OS Option Ready?
E46BA Tool Presetter 400mm 600mm Pneumatic Motorised Mechanical 1 µm 18X Elbo-Controlli FLASH
