One of our largest rotary tables, the 5AX-1200 is designed for gantry type systems, machining centres and 5-plane machines.

Manufactured with a powerful double clamping system on both ends of the tilting axis and an optional counterbalance weight installation option for the 5AX-1200A sister machine, the 5AX-1200 is designed to maintain precision and have life long durability.

5AX-1200 5th Axis Rotary Table
5AX-1200 5th Axis Rotary Table Technical Diagram

Nikken Rotary Table Catalogue – 2019

(PDF - 62.5 MB)

5AX-1200
Face Plate Diameter[Ømm] 1200
Table Range/Type EXTRA LARGE
Diameter of Spindle Hole [Ømm H7] 300
Number of Spindles x Pitch [mm] 1
Centre Height (90°) [mm] 750
Table Height in Horizontal Position (0°) [mm] 950
Width of T Slot [mm] 22
AXIS Rotary Tilting (0°-105°)
Clamping System HYD HYD
Clamping Torque [Nm] 14700 19600
Table Inertia at Motor Shaft [Kg m2 x 103] 10.8 3.5
Servo Motor [min1] αiF22·2000 αiF22·2000
Min. Increment [Degrees] 0.001 0.001
Rotation Speed [min1] 5.5 2.7
Total Reduction Ratio 1/360 1/720
Indexing Accuracy [sec] 20 60
Indexing Accuracy Ultra Precision [sec] ±5 ±10
Net Weight [Kg] 7300
Max. Work Load on Table 0° to 30° [Kg] 2500
Max. Work Load on Table 30° to 90° [Kg] 1500
Max. Thrust Load at Table Centre - Tilting Angle = 0° [N] 137200
Max. Thrust Load 'F' @ 'Lmm' from Table Centre - Tilting Angle = 0° [N] 5488
Max. Thrust Load 'F' @ 'Lmm' from Table Faceplate - Tilting Angle = 90° [N] 9600
Strength of Worm Wheel Without Brake (Against Dynamic Cutting Thrust) - Tilting Angle = 90° [FxL Nm] 14700
Max. Work Inertia [Kg m2] 276
Driving Torque [Nm] 3168
