The powerful 5AX-800 Rotary Table is ideal for achieving unmatched high precision and performance.
Designed for gantry type systems, machining centres and 5-plane machines, the 5AX-800 has a powerful double clamping system on both ends of the tilting axis, offering high rigidity and durability for multiple-axis machining.
Like all NIKKEN products, the 5AX-800 is designed for easy maintenance and life long durability.
![5AX-800 5th Axis Rotary Table](/rails/active_storage/representations/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaHBBbHNGIiwiZXhwIjpudWxsLCJwdXIiOiJibG9iX2lkIn19--c58e48cfef69ab153386624732ab0fa65400157f/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaDdCam9VWTI5dFltbHVaVjl2Y0hScGIyNXpld2s2RUdGMWRHOWZiM0pwWlc1MFZEb01aM0poZG1sMGVVa2lDMk5sYm5SbGNnWTZCa1ZVT2d0eVpYTnBlbVZKSWcwNE1EQjRORFV3WGdZN0NGUTZDV055YjNCSkloQTRNREI0TkRVd0t6QXJNQVk3Q0ZRPSIsImV4cCI6bnVsbCwicHVyIjoidmFyaWF0aW9uIn19--504807c00c81bc60c54f8203f5b100694120b648/CNC1000_5AX-800.jpg)
![5AX-800 5th Axis Rotary Table Technical Diagram](/rails/active_storage/representations/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaHBBbFlHIiwiZXhwIjpudWxsLCJwdXIiOiJibG9iX2lkIn19--6cf420cff3afbf3ad567f8bb8722de7cf504d621/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaDdCam9VWTI5dFltbHVaVjl2Y0hScGIyNXpld2s2RUdGMWRHOWZiM0pwWlc1MFZEb01aM0poZG1sMGVVa2lDMk5sYm5SbGNnWTZCa1ZVT2d0eVpYTnBlbVZKSWcwNE1EQjRORFV3WGdZN0NGUTZDV055YjNCSkloQTRNREI0TkRVd0t6QXJNQVk3Q0ZRPSIsImV4cCI6bnVsbCwicHVyIjoidmFyaWF0aW9uIn19--504807c00c81bc60c54f8203f5b100694120b648/5AX-800-100.jpg)
Nikken Rotary Table Catalogue – 2019
(PDF - 62.5 MB)
5AX-800 | ||
---|---|---|
Face Plate Diameter[Ømm] | 800 x 500 | |
Table Range/Type | EXTRA LARGE | |
Diameter of Spindle Hole [Ømm H7] | 130 | |
Number of Spindles x Pitch [mm] | 1 | |
Centre Height (90°) [mm] | 550 | |
Table Height in Horizontal Position (0°) [mm] | 500 | |
Width of T Slot [mm] | 14 | |
AXIS | Rotary | Tilting (0°-105°) |
Clamping System | HYD | HYD |
Clamping Torque [Nm] | 4655 | 6125 |
Table Inertia at Motor Shaft [Kg m2 x 103] | 6.8 | 6 |
Servo Motor [min1] | αiF22·2000 | αiF40·2000 |
Min. Increment [Degrees] | 0.001 | 0.001 |
Rotation Speed [min1] | 25 | 12.5 |
Total Reduction Ratio | 1/60 | 1/120 |
Indexing Accuracy [sec] | 20 | 60 |
Indexing Accuracy Ultra Precision [sec] | ±5 | ±10 |
Net Weight [Kg] | 2300 | |
Max. Work Load on Table 0° to 30° [Kg] | 500 | |
Max. Work Load on Table 30° to 90° [Kg] | 300 | |
Max. Thrust Load at Table Centre - Tilting Angle = 0° [N] | 31360 | |
Max. Thrust Load 'F' @ 'Lmm' from Table Centre - Tilting Angle = 0° [N] | 2695 | |
Max. Thrust Load 'F' @ 'Lmm' from Table Faceplate - Tilting Angle = 90° [N] | 2824 | |
Strength of Worm Wheel Without Brake (Against Dynamic Cutting Thrust) - Tilting Angle = 90° [FxL Nm] | 2548 | |
Max. Work Inertia [Kg m2] | 23 | |
Driving Torque [Nm] | 422 |
