The powerful 5AX-T400 Built-In Rotary Table is ideal for achieving unmatched high precision and productivity.
Having a powerful hydraulic clamping system, the 5AX-T400 offers high strength and rigidity while maximising clearance. Featuring an optional built-in type 8 ports rotary joint attachment and right or left motor positioning, the 5AX-T400 guarantees high performance and accuracy.
Like all NIKKEN products, the 5AX-T400 is designed for easy maintenance and life long durability.
![5AX-T400 5th Axis Rotary Table](/rails/active_storage/representations/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaHBBbDBGIiwiZXhwIjpudWxsLCJwdXIiOiJibG9iX2lkIn19--41c7dc1888dc71089880306e3fce4a574349db82/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaDdCam9VWTI5dFltbHVaVjl2Y0hScGIyNXpld2s2RUdGMWRHOWZiM0pwWlc1MFZEb01aM0poZG1sMGVVa2lDMk5sYm5SbGNnWTZCa1ZVT2d0eVpYTnBlbVZKSWcwNE1EQjRORFV3WGdZN0NGUTZDV055YjNCSkloQTRNREI0TkRVd0t6QXJNQVk3Q0ZRPSIsImV4cCI6bnVsbCwicHVyIjoidmFyaWF0aW9uIn19--504807c00c81bc60c54f8203f5b100694120b648/CNC1000_5AX-T400.jpg)
![5AX-T400 5th Axis Rotary Table Technical Diagram](/rails/active_storage/representations/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaHBBbDBHIiwiZXhwIjpudWxsLCJwdXIiOiJibG9iX2lkIn19--22e7f944541de5763580f7a8e4d8ce72e7b99667/eyJfcmFpbHMiOnsibWVzc2FnZSI6IkJBaDdCam9VWTI5dFltbHVaVjl2Y0hScGIyNXpld2s2RUdGMWRHOWZiM0pwWlc1MFZEb01aM0poZG1sMGVVa2lDMk5sYm5SbGNnWTZCa1ZVT2d0eVpYTnBlbVZKSWcwNE1EQjRORFV3WGdZN0NGUTZDV055YjNCSkloQTRNREI0TkRVd0t6QXJNQVk3Q0ZRPSIsImV4cCI6bnVsbCwicHVyIjoidmFyaWF0aW9uIn19--504807c00c81bc60c54f8203f5b100694120b648/5AX-T400-100.jpg)
Nikken Rotary Table Catalogue – 2019
(PDF - 62.5 MB)
5AX-T400 | ||
---|---|---|
Face Plate Diameter[Ømm] | 400 | |
Table Range/Type | BUILT-IN | |
Diameter of Spindle Hole [Ømm H7] | 105 | |
Number of Spindles x Pitch [mm] | 1 | |
Centre Height (90°) [mm] | 390 | |
Table Height in Horizontal Position (0°) [mm] | 390 | |
Width of T Slot [mm] | 14 | |
AXIS | Rotary | Tilting (0°-105°) |
Clamping System | HYD | HYD |
Clamping Torque [Nm] | 1760 | 1760 |
Table Inertia at Motor Shaft [Kg m2 x 103] | 2.8 | 2.44 |
Servo Motor [min1] | αiF12·2000 | αiF22·2000 |
Min. Increment [Degrees] | 0.001 | 0.001 |
Rotation Speed [min1] | 22.2 | 16.6 |
Total Reduction Ratio | 1/90 | 1/120 |
Indexing Accuracy [sec] | 15 | 60 |
Indexing Accuracy Ultra Precision [sec] | - | - |
Net Weight [Kg] | 995 (750 Without Base) | |
Max. Work Load on Table 0° to 30° [Kg] | 300 | |
Max. Work Load on Table 30° to 90° [Kg] | 250 | |
Max. Thrust Load at Table Centre - Tilting Angle = 0° [N] | 31360 | |
Max. Thrust Load 'F' @ 'Lmm' from Table Centre - Tilting Angle = 0° [N] | F6860 @ L=200 | |
Max. Thrust Load 'F' @ 'Lmm' from Table Faceplate - Tilting Angle = 90° [N] | F11660 @ L=100 | |
Strength of Worm Wheel Without Brake (Against Dynamic Cutting Thrust) - Tilting Angle = 90° [FxL Nm] | 1166 | |
Max. Work Inertia [Kg m2] | 5.1 | |
Driving Torque [Nm] | 432 |
